4
Model assembly
Wing installation
Installation of the landing gear set
1. With the fuselage inverted, slide the
landing gear into the fuselage slots as shown.
1. Slide the wing spar into the fuselage pass
through.
2. Slide the landing gear retainers into the
fuselage slots and secure the assembly using
the included screws.
2. Attach the wing struts to the wing as
shown.
To Next Page
