5
Model assembly
Wing installation
Horizontal and vertical stabilizer installation
3. With the fuselage inverted, connect the aile-
ron servo wire then secure the wing and wing
struts using the included screws.
1. Place the horizontal stabilizer onto the fuse-
lage cutout.
2. Place the vertical stabilizer onto the
horizontal stabilizer. Secure using the
included screw.
3. Attach both tailfins to the fuselage using
the included screws.
