6
Model assembly
Puhsrod installation
Antenna installation
Propeller and spinner installation
1. With the servo and elevator centered,
connect the servo to the control surface using
a pushrod.
2. With the servo and rudder centered, con-
nect the servo to the control surface using a
pushrod.
1. Place the antennae into their positions on
top of the wings as shown, then push them
aft to secure.
1. The propeller and spinner are secured onto
the motor shaft in the order shown.
