Page: 9Rev Date: 1/20/2017Doc Number: D1092Initials: RF
Figure 5.
Figure 6.
2.3.2 JOIN - The Key-Lock plates
• Press both Key-Lock plates
together keeping a rm hold
while locating the tail lock
plate.
2.3.3 GRAB - The tail lock plate
• Grab the ARV-QC tail and pull it up between
the legs of the victim.
• Optionally, this device can be secured and
own in the method detailed in section 2.4.1
- Quick Pick Conguration.
