User’s manual – AK32 EMBEDDED SYSTEM VOICE LOGGER
23
Channel No.01-32. Black label is for Card No. 1-4.
Card 1: Channel 01-08
Card 2: Channel 09-16
Card 3: Channel 17-24
Card 4: Channel 25-32
Recording announcement enabled indicator.
Mute enabled indicator. Enabled/Disabled by specific hot key
Green: Disable
Red: Enable
Monitor indicator. Only one channel can be monitored by a PC
Headset symbol: Being monitored.
Refresh current status to PC
Display:
Program will display time, channel status, recording file, etc. User can hide some of them.
