User’s manual – AK32 EMBEDDED SYSTEM VOICE LOGGER
Save or not save indicator.
AK32 will not save the calls for following situations
a. Hot-t key recording. The call is unable to be saved until the
specified hot-key is pressed
b.Polarity reversal recording. The call is unable to be saved
until polarity reversal signal received.
C. Not record phone and extension number. Be out of
recording time section.
AGC indicator
AGC: Automatic Gain Control
Channel Status
Indicate channel status. Include: idle, power off, dialing, etc
Current channel voltage
No landline in: 1-3 V Power off
Idle: >30V
Dialing: 5-24V
Create recording file establishing indicator
Indicate whether AK32 is recording calls properly. If the HDD is
disconnected or unformatted, the indicator will not appear.
Suggest: Record the calls 1min after AK32 power on.
