36
2.3.2 Setting Data
Motor tag information and learning settings can be entered from Settings Data menu. Motor tag
information can also be entered from the Commission menu. Select the parameter to be adjusted
with up-down arrow keys and press OK button. Enter the value on the incoming numerical number
entry screen by using right-left and up-down buttons and press the OK button. After all entries are
made, press SET to save all changes.
Parameter
Description
Motor Nominal Voltage
Fill with motor nominal voltage (L-N)
Motor Nominal Current
Fill with motor nominal current
Star / Delta
If motor connection type is star set 0, if
not 1
Motor Nominal Frequency
Nominal line frequency or most
common inverter
operating frequency
Learn Iteration
The number of data acquisition
iterations required for a LEARN period.
