2.2 Voltage Input Terminal
This is the terminal for measuring motor input v o l t a g e . Input voltage must be max. 690Vrms line
to line.
Pin No
Description
L1
Connecting to R p hase
L2
Connecting to S p hase
L3
Connecting to T p hase
