950-0027-01, Rev. B English
950-0027-01B 1 of 55
Synergy
HD3
System
Instructions for Use
The Arthrex Synergy
HD3
System Camera Controller and
Camera Head User’s Guide provides important
information for the safe operation of all components of the
Synergy
HD3
Camera System, including accessories. Read
this User’s Guide thoroughly prior to using this system
and keep it in an easily accessible place for use by all
operating personnel. Read and follow all safety warnings,
cautions and precautions.
Arthrex, Inc.
1370 Creekside Blvd.
Naples, FL 34108, USA
+1 (800) 934-4404
Technical Support
1-800 391-8599
EC
REP
Arthrex GmbH
Erwin-Hielscher-Strasse 9
81249 München, Germany
+49 89 909005-0

Table of Contents

Questions and Answers

  • V
    victoria08Aug 7, 2025
    What to do if there is no video image on the Arthrex Digital Camera monitor?
    • T
      Tyler McculloughAug 7, 2025
      If you're not seeing a video image on the monitor with your Arthrex Digital Camera, first ensure that the CCU and monitor are plugged in and powered on. Next, confirm all cable connections are correct and reroute video cables if needed, checking for any damage and replacing cables as necessary. Also, make sure the camera head cable connector is fully inserted into the console's receptacle. If the issue persists, try replacing the camera head with a known working unit to see if the original camera head or cable is faulty and needs repair.
  • R
    Richard GibsonAug 12, 2025
    How to fix an Arthrex AR-3200-0001T that does not power up?
    • A
      Amy JimenezAug 12, 2025
      If your Arthrex Digital Camera isn't powering up, and the standby LED isn't lit, start by ensuring the power cord is securely plugged into both the CCU and a properly grounded receptacle. If it's still not working, try replacing the power cord to rule out a faulty cord.
  • J
    Jennifer JohnsonAug 18, 2025
    What to do if Arthrex AR-3200-0001T has an intermittent picture?
    • T
      thomaswilsonAug 18, 2025
      If you are experiencing an intermittent picture with your Arthrex Digital Camera, first, reinsert the camera head connector card edge to ensure it's fully seated in the CCU camera receptacle. Then, flex the video and power cables to see if the picture is affected; if it is, inspect the cables and replace them if necessary. If flexing the camera cable affects the picture, it may need to be returned for repair or replacement.
  • N
    nicholas69Aug 22, 2025
    Why won't my Arthrex AR-3200-0001T white balance?
    • K
      Kathleen AguirreAug 22, 2025
      If your Arthrex Digital Camera won't white balance, and the monitor indicates “White Balance Fail”, it could be due to several reasons: * Too much light: Move the scope further from the white gauze or reduce the light source brightness. * Too little light: Move the scope closer to the white gauze or increase the light source brightness. * Wrong color temperature light: Adjust the light source to the correct color temperature.
  • B
    Brian HodgeAug 27, 2025
    How to improve color reproduction on Arthrex AR-3200-0001T?
    • D
      davidmendozaAug 27, 2025
      If you're experiencing poor color reproduction with your Arthrex Digital Camera, the issue is likely due to white balance problems. Try white balancing the camera head to resolve this.
  • D
    David ChanSep 2, 2025
    What to do if Arthrex Digital Camera head buttons do not function?
    • D
      Dustin DouglasSep 2, 2025
      If the camera head buttons on your Arthrex Digital Camera aren't functioning as programmed, it's likely due to incorrect programming. Reprogram the camera head buttons to resolve this issue. Note that this solution is only applicable if you are using the Tablet Data Input device option.

Summary

Introduction and Safety Guidelines

System Intended Use and Contraindications

Critical Safety Warnings and Precautions

Explains safety symbols and lists critical operational warnings and precautions.

Device Handling and Initial Use

Initial Use and Setup Precautions

System Indicators and Panel Descriptions

Rear Panel Connections

System Installation and Operation

System Installation Steps

Step-by-step guide for interconnecting system components.

Operation with Data Input Device

Overview of operating the system using the tablet data input device.

Accessories for Intended Use

System Setup and Surgeon Preferences

Surgeon Management and Preferences

Print Field Configuration

Network Configuration

Surgeon Management and Procedures

Adding Surgeons and Procedures

Surgeon Preferences Settings

Procedure Preferences and Camera Settings

Surgeon-Specific Camera Settings

Scheduling and Starting Cases

Scheduling a New Case

Steps to schedule a new patient case using the "+ Add New Case" icon.

Starting and Ending Cases

Procedures to select, start, and properly end patient cases.

System Operation Without Tablet Input

Operation via Front Panel Controls

Operating the system using front panel controls, including white balance.

Picture in Picture (PIP) Functionality

Maintenance Overview

Cleaning and Sterilization Procedures

Detailed instructions for cleaning and sterilizing the CCU and camera heads.

Troubleshooting and Material Compatibility

Troubleshooting Common Issues

Guides users through diagnosing and resolving common system problems.

CCU Maintenance and Battery Replacement

Technical Information and Certifications

System Classification and Safety Certifications

EMC Certifications and CE Marking

Detailed EMC Information

EMC Guidance and Mitigation Measures

Explains EMC limits, potential interference, and mitigation measures.

EMC Warnings and Precautions

Arthrex AR-3200-0001T Specifications
