AP-270 Series Outdoor Access Point | Installation Guide 3
AP-270 Series Hardware Overview
Figure 1 AP-275 Front View
Figure 2 AP-274 Front View (Aesthetic Cover Removed)
LED
The AP-270 Series is equipped with one LED that indicates the system status of the AP.
The antenna connectors of AP-274 are covered by an aesthetic cover in the package. The aesthetic cover can be
removed when necessary.
