Aruba 303H Series Hospitality Access Point | Installation Guide 3
Table 2 Radio Status LEDs
Network Status
The Network Status LED, located on the sides of the E1-E3 ports, indicates activity transmitted to/from the wired
ports, as shown in Table 3.
Table 3 Network Status LEDs
PoE-PSE Status
The PoE-PSE LED are located above ports E1-E3, and indicate when the access point is operating as Power
Sourcing Equipment (PSE), providing Power over Ethernet (PoE) to an external device that is physically connected
to the E3 port by Ethernet cable, as shown in Table 4.
Table 4 PoE-PSE Status LEDs
LED Display Settings
The LEDs have three operating modes that can be selected in the system
management software:
 Default mode: Refer to Tables 1-3
 Off mode: LEDs are off
Color/State Meaning
Off Meets one of the following conditions:
 both radios are disabled
 device is powered off
Green/solid Both radios enabled in access mode
Green/blinking
1 One radio enabled in access mode; one radio
disabled
Amber/solid Both radios enabled in monitor mode
Amber/flashing Device ready; operating in power-save mode, with uplink negotiated at
suboptimal speed (<1Gbps)
Alternating
3
Error condition
Color/State Meaning
Off Meets one of the following conditions:
 device is powered off
 port is disabled
 no link/activity
Green/solid Link established at max speed (1Gbps)
Green/blinking Activity detected across a max speed link
Amber/solid Link established at reduced speed (10/100Mbps)
Amber/blinking Activity detected across a reduced speed link
Color/State Meaning
Off Access point not supplying PoE, or powered off
Green/solid Access point supplying power to a connected device
Green/blinking Negotiating PoE power supplied to a connected device
