Explanation of the symbols
Symbols in the instructions
In these operating instructions, the following
symbols are used to denote special dangers.
Warning.
These symbols denote special
dangers.
Prohibition sign.
These symbols denote
inadmissible procedures.
Directive sign.
These symbols denote required
protective measures.
Symbols on the device
The following symbols are placed on the
device to inform you must be careful and
attentive when using the device:
Working with the device
requires extreme cautiousness.
Read the operating instructions
before you use the device.
Min. 15 m.
Risk of injury!
Make sure that no one is within
the danger zone of the device.
Objects may be ejected. The
danger zone extends for at
least 15 metres.
The quickly rotating blade can
cause life threatening injuries or
immense property damage! Be
especially careful to keep your
hands and feet away from the
blade when the device is put
into operation.
Prior to any repair and
maintenance work, pull off the
spark plug connector.
Clean the ventilation grid!
The cooling air of the
motor is sucked in through
the ventilation grid of the
engine cover. Always keep
the entire surface open
and free!
Noise is causing health
problems. Use personal ear
protection to avoid hearing
damage.
Type plate
The type plate on the device provides you
with information on the device type and the
technical data.
1
2
3
5
6
7
8
Rasenmäher
4,4 kW (6,0 PS) / 2800 (1/min)
68 kg
2011
SNR: 020909090055
AS-MOTOR GERMANY GmbH & Co KG
Ellwanger Stra ße 15
D-74424 Bühlertann
1003s
AS 53 B6 RB-Kat
9
1
2
3
4
5
6
7
8
9
Name and address of the
manufacturer
Device designation
Type designation
Rated power output in kW / engine
speed
Weight
Year of manufacture
Serial number
CE marking
Sound level L
WA
