Operating Instructions
Allmäher®
AS 21 2T + AS 26 2T
From serial number: 020211040001 + 020011040001
Issued: 18.02.2015, V14.0
EN-Translation of the Original Operating Instructions

Questions and Answers

  • T
    Tammy HamiltonAug 17, 2025
    Why AS MOTOR AS 26 2T Lawn Mower engine starts badly?
    • J
      John AndersonAug 17, 2025
      If your AS MOTOR Lawn Mower engine starts poorly or runs irregularly, the choke might be closed (open it). Another potential cause is a dirty air filter, so you should maintain it. Also, using poor quality, dirty, or old fuel can cause this issue; always use fresh fuel.
  • M
    Michael PetersonAug 20, 2025
    How to fix uneven cut with AS MOTOR AS 26 2T Lawn Mower?
    • S
      Sarah JimenezAug 21, 2025
      If your AS MOTOR Lawn Mower is leaving an uneven cut, making your lawn look unsightly, it could be due to a dull or worn blade. Have the blade resharpened and balanced or replaced. Also, check if your speed is too high for the cutting height; reduce the speed and select the correct cutting height. Lastly, a heavily contaminated mower housing can cause this, so clean it thoroughly.
  • W
    William ColemanAug 25, 2025
    Why AS MOTOR AS 26 2T has strong vibrations?
    • Y
      yvonne08Aug 25, 2025
      Strong vibrations during operation of your AS MOTOR Lawn Mower can be caused by several issues. An unbalance at the blade, due to incorrect sharpening or chips, can cause vibrations; have the blade resharpened and balanced by an authorised service centre, and replace a damaged blade immediately. Other potential causes that require professional attention include a bent blade drive shaft, loose engine fastening, or loose blade fastening.
  • W
    William JonesAug 28, 2025
    What to do if AS MOTOR Lawn Mower engine gets hot?
    • W
      wrightsethAug 29, 2025
      If your AS MOTOR Lawn Mower engine is getting too hot, it might be because the ventilation grid is dirty, so clean it. Another possible reason is that the cooling fins of the engine are dirty and should be cleaned by an authorised service centre.
  • E
    Edward Moore DDSSep 1, 2025
    What to do if discharge channel is jammed in AS MOTOR AS 26 2T?
    • D
      Douglas CarterSep 1, 2025
      If the discharge channel of your AS MOTOR Lawn Mower is jammed, it could be because the mowed grass was too long or too damp. Adjust the cutting height and mowing speed to suit the mowing conditions. Alternatively, the blade may be worn or the engine speed may be too low despite full power, both of which require attention from an authorised service centre.
  • K
    Kimberly SalasSep 5, 2025
    What to do if AS MOTOR Lawn Mower engine does not switch off?
    • J
      john08Sep 5, 2025
      If the engine of your AS MOTOR Lawn Mower does not switch off, the switching off system is likely defective. Close the fuel valve and seek assistance from an authorised service centre.
  • E
    Eileen KingSep 9, 2025
    How to fix if the blade slides on AS MOTOR Lawn Mower?
    • J
      Jody ThomasSep 9, 2025
      To address a sliding blade issue on your AS MOTOR Lawn Mower, replace the friction discs.
  • O
    ososaNov 12, 2025
    Why my AS MOTOR Lawn Mower engine does not start?
    • J
      Jordan WatsonNov 13, 2025
      If your AS MOTOR Lawn Mower's engine won't start, several factors could be at play. First, make sure the engine brake lever is pressed towards the handlebar. Check that the fuel valve and tank ventilation screw are open, and that there's enough fuel in the tank. Ensure the choke is closed. If the engine was flooded from too many start attempts, remove the spark plugs, close the fuel valve, open the choke, set to full throttle and start it a few times to dry it out. Then, dry the spark plugs and reinstall them. Also, verify the spark plug connector is properly attached. Other potential issues include a dirty air filter (maintain it), sooted or damaged spark plugs (clean or replace them), a jammed mower housing (see maintenance instructions), or poor quality fuel (clean the fuel system and u...

Summary

Intended Use

Safety Instructions

Get Informed!

Emphasizes reading instructions, familiarizing with controls, and seeking dealer guidance.

User Restrictions and Hours of Operation

Outlines who is permitted to operate the device and age/condition limitations.

Safe Handling of Fuel

Provides critical safety guidelines for handling flammable fuel and preventing hazards.

Prior to Mowing

Personal Protective Measures

Specifies required personal protective equipment (PPE) for mowing operations.

Use Caution When Mowing

General advice and warnings to ensure safe mowing practices.

Use Caution During Maintenance and Repair

Device Description

Control Elements

Assembly

Information on Mowing

Fuel

Details on the correct type of fuel and oil mixture required for the engine.

Starting

Starting Device

Step-by-step instructions on how to start the engine using the starting mechanism.

Switching Off and Parking

Maintenance and Cleaning

Maintaining the Engine

Maintaining the Air Filter

Procedures for cleaning or replacing the air filter for optimal engine performance.

Checking the Drive

Checking the Blade

Blade Change

Checking Engine Brake

Storage

Troubleshooting

Mixing Ratios Fuel

Technical Data

AS MOTOR AS 26 2T Specifications

General IconGeneral
BrandAS MOTOR
ModelAS 26 2T
CategoryLawn Mower
LanguageEnglish
