INSTALLATION
IM14229-13
GB
G 1/4
Weight: 0,850 kg
G 1/8
Weight: 0,550 kg
max. 145
PE(M4; 8)
18
25
34.8
29
25
10
26.6
80.5
3xG1/8"; 8
57
25
15
max.175
3xG1/4"; 12
PE(M4; 8)
36
68
105.2
55.3
45.3
11.02
34.8
43
52
10
30
*
*
26
8. DIMENSIONS (mm), WEIGHT (kg)
Sentronic
PLUS
- Digital electronic pressure regulator valve with 7-pin DIN connector
