INSTALLATION
IM14229-14
GB
G 1
Weight: 3,400 kg
max.197
100.7
60
68
45.5
3xG1"; 18
PE(M4; 8)
100
80
20
48
15
79
96
60
34.8
Weight: 1,650 kg
G 1/2
max.185
45
53
34.5
136
81
63.5
15
40
12
57.5
70
45
34.8
PE(M4; 8)
3xG1/2"; 14
8. DIMENSIONS (mm), WEIGHT (kg)
Sentronic
PLUS
- Digital electronic pressure regulator valve with 7-pin DIN connector
