TD 92351GB
2007-03-15/ Ver. C
User Manual
Ascom a51 Alarm Transmitter
12
Replace the Name Label
Open the battery lid, see section Replace the Battery above, replace the old name label
with a new from the Name label kit (extra ordered).
Restore the Clip
The clip has a special release function to prevent it from breaking when strained. When
the clip is released and becomes slack, just snap it back with a hard press.
If the clip has fallen entirely off its fastening, perform the following:
1 Put the axle of the link clip in the closed hole on the clip, see 1.
2 Push the axle until it snaps into the open hole in the clip.
3 Snap the clip to the Alarm Transmitter with a hard press.
Figure 8.
1
2
009
3
Figure 8. How to restore the clip.
7 Related Documents
Installation and Operation Manual, Portable Device Manager TD92325GB
