ACK-E-2009 Electrical Data
Electrical Data
Electrical Data - Cooling Only (R22)
MODEL
INDOOR UNIT ACK 20E ACK 25E
OUTDOOR UNIT ALC 20C ALC 25C
INDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 89 103
RATED RUNNING CURRENT A 0.40 0.45
MOTOR OUTPUT W 20 30
POLES 66
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 114 134
RATED RUNNING CURRENT A 0.53 0.59
MOTOR OUTPUT W 42 64
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR μF 50 50
RATED INPUT POWER W 1757 2303
RATED RUNNING CURRENT A 7.9 10.4
LOCKED ROTOR AMP A 35 / 39 (220 / 240) 52
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
MODEL
INDOOR UNIT ACK 28E
OUTDOOR UNIT ALC 28C
INDOOR MOTOR
INSULATION GRADE CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
RATED INPUT POWER W 152
RATED RUNNING CURRENT A 0.57
MOTOR OUTPUT W 50
POLES 6
OUTDOOR MOTOR
INSULATION GRADE CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
RATED INPUT POWER W 142
RATED RUNNING CURRENT A 0.62
MOTOR OUTPUT W 75
POLES 6
COMPRESSOR
INSULATION GRADE CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
CAPACITOR μF 60
RATED INPUT POWER W 2426
RATED RUNNING CURRENT A 11.0
LOCKED ROTOR AMP. A 62
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
