78
ACK-E-2009 Performance Data
Cooling Only (R22)
Model: ACK 20E - ALC 20C
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 6.886 4.269 6.371 3.821 5.857 3.373 5.343 2.925 4.828 2.477 4.211 1.939
16 6.843 3.738 6.368 3.391 5.893 3.043 5.419 2.695 4.944 2.347 4.374 1.93
24
16 6.843 4.983 6.368 4.635 5.893 4.287 5.419 3.94 4.944 3.592 4.374 3.175
17 6.799 4.452 6.365 4.205 5.93 3.957 5.495 3.71 5.06 3.463 4.538 3.166
18 6.756 3.921 6.361 3.774 5.966 3.627 5.571 3.48 5.176 3.333 4.702 3.157
19 6.713 3.39 6.358 3.344 6.002 3.297 5.647 3.25 5.292 3.204 4.865 3.148
20 6.67 2.856 6.351 2.879 6.032 2.902 5.713 2.926 5.394 2.949 5.011 2.977
28
18 6.756 5.166 6.361 5.019 5.966 4.872 5.571 4.725 5.176 4.578 4.702 4.401
19 6.713 4.635 6.358 4.588 6.002 4.542 5.647 4.495 5.292 4.448 4.865 4.392
20 6.67 4.1 6.351 4.124 6.032 4.147 5.713 4.17 5.394 4.193 5.011 4.221
21 6.626 3.563 6.341 3.636 6.056 3.709 5.771 3.782 5.487 3.855 5.145 3.943
22 6.582 3.026 6.331 3.149 6.081 3.272 5.83 3.395 5.58 3.517 5.279 3.664
23 6.538 2.489 6.322 2.662 6.105 2.834 5.889 3.007 5.673 3.179 5.413 3.386
24 6.494 1.952 6.312 2.175 6.13 2.397 5.948 2.619 5.766 2.841 5.547 3.107
30
20 6.67 4.723 6.351 4.746 6.032 4.769 5.713 4.793 5.394 4.816 5.011 4.844
21 6.626 4.186 6.341 4.259 6.056 4.332 5.771 4.405 5.487 4.478 5.145 4.565
22 6.582 3.649 6.331 3.771 6.081 3.894 5.83 4.017 5.58 4.14 5.279 4.287
23 6.538 3.112 6.322 3.284 6.105 3.457 5.889 3.629 5.673 3.801 5.413 4.008
24 6.494 2.575 6.312 2.797 6.13 3.019 5.948 3.241 5.766 3.463 5.547 3.73
Model: ACK 25E - ALC 25C
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 8.301 5.301 7.8 4.867 7.299 4.433 6.798 3.998 6.297 3.564 5.695 3.043
16 8.436 4.744 7.955 4.391 7.474 4.037 6.992 3.684 6.511 3.33 5.933 2.906
24
16 8.436 6.081 7.955 5.728 7.474 5.374 6.992 5.021 6.511 4.667 5.933 4.243
17 8.572 5.524 8.11 5.251 7.648 4.979 7.186 4.706 6.725 4.433 6.171 4.106
18 8.707 4.967 8.265 4.775 7.823 4.583 7.381 4.391 6.939 4.199 6.408 3.969
19 8.842 4.411 8.42 4.299 7.997 4.188 7.575 4.077 7.153 3.965 6.646 3.832
20 8.976 3.852 8.565 3.802 8.153 3.753 7.742 3.703 7.331 3.654 6.837 3.594
28
18 8.707 6.304 8.265 6.112 7.823 5.92 7.381 5.728 6.939 5.536 6.408 5.306
19 8.842 5.748 8.42 5.636 7.997 5.525 7.575 5.413 7.153 5.302 6.646 5.168
20 8.976 5.189 8.565 5.139 8.153 5.09 7.742 5.04 7.331 4.991 6.837 4.931
21 9.109 4.628 8.703 4.628 8.297 4.628 7.891 4.627 7.485 4.627 6.997 4.627
22 9.243 4.067 8.842 4.117 8.441 4.166 8.039 4.215 7.638 4.264 7.157 4.323
23 9.376 3.507 8.98 3.605 8.584 3.704 8.188 3.802 7.792 3.901 7.317 4.019
24 9.509 2.946 9.119 3.094 8.728 3.242 8.337 3.39 7.946 3.538 7.477 3.715
30
20 8.976 5.857 8.565 5.807 8.153 5.758 7.742 5.708 7.331 5.659 6.837 5.6
21 9.109 5.296 8.703 5.296 8.297 5.296 7.891 5.296 7.485 5.296 6.997 5.296
22 9.243 4.736 8.842 4.785 8.441 4.834 8.039 4.883 7.638 4.933 7.157 4.992
23 9.376 4.175 8.98 4.274 8.584 4.372 8.188 4.471 7.792 4.569 7.317 4.688
24 9.509 3.615 9.119 3.763 8.728 3.91 8.337 4.058 7.946 4.206 7.477 4.384
08_Performance Data_A.indd 7808_Performance Data_A.indd 78 4/6/2009 11:14:02 AM4/6/2009 11:14:02 AM
