Exploded View and Part List ACK-E-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
OUTDOOR UNIT
MODEL: A5LC 35/40/50CR
No Description Part Number
1 Assy. Base Pan R50014053238
2 Assy. 3 Way VLV 3/8” R50059017536
3 Assy. 3 Way VLV 5/8” R50059030530
4 Assy, Partition R50014053277
5 Compressor
A5LC 35CR (1 Phase) R50049025547
A5LC 35CR (3 Phase) R50049025336
A5LC 40CR (1 Phase) R50049028527
A5LC 40CR (3 Phase) R50049025380
A5LC 50CR R50049022878
6 Service Panel R01010029898
7 Accumulator R02119031841
8 Panel, Back Right R01014053233
9 Top Panel R01011029900
10 Assy. Coil
A5LC 35CR R50024082878
A5LC 40CR R50024076551
A5LC 50CR R50024084456
11 Fan Motor Bracket R01014053232
12 Panel Side Left R01010029899
13 Fan Motor R03039004046
14 Fan Blade R03013028160
15 Front Panel R50014053236
16 Valve Plate R01013034235
Parts Not in Diagram
Capacitor, Compressor
A5LC 35/40CR R04029026777
No Description Part Number
Capacitor, Fan Motor
A5LC 35CR R04029026782
A5LC 40CR R04029026761
A5LC 50CR R04029026767
Pressure Switch 7PSI N/C R04109015400
Pressure Switch 600PSI N/C
R04104061879
Contactor R04039018866
Fan Guard R01023030109
Assy. Terminal Board Main
A5LC 35CR (1 Phase) R50044090632
A5LC 40CR (1 Phase) R50044090633
A5LC 35CR (3 Phase) R50044082801
A5LC 40CR (3 Phase) R50044083125
A5LC 50CR R50044098922
Phase Protector, PP1.03 R04089017029
Handling Handle R12014015328
TXV Valve R05019020252
Valve Access R05014070450
Assy. Cap Tube
A5LC 35CR R50024095660
A5LC 40CR R50024095119
A5LC 50CR R50024099359
Assy. Acumulator Clip R50014014462
Cover, Terminal Board R01014029893
Valve, Rev 4-Way R05019019861
