Page 16
Maintenance
When Fusion becomes dirty it can be cleaned with a
damp cloth and mild detergent. Do not use solvents
or abrasive cleaning agents as they can mark the
display area. If dust appears on the image use a lens
cleaning cloth supplied to clean the mirror of the
mouse camera. When cleaning the mirror, be very
gentle as the silver surface can scratch very easily.
Technical Description
The Fusion unit should not be opened there are no
user serviceable parts inside. Refer servicing to
Qualified Persons only.
Size, Weight 175 x 188 x 96mm, 1.1 kg (6.9”x 7.4”x3.8”, 4 lb
11 oz)
Power
consumption:
15W operating, 35W recharging and operating.
Voltage: 100-240V AC, 50/60Hz.
Input to Fusion: 12V dc center positive 5A
Battery: Custom Li-Ion rechargeable batteries.
Typical battery life is 3 hours but will vary
depending on the backlight brightness.
Screen: High brightness 7” (17.8cm) diagonal TFT display.
Magnification
7x - 17x continuous zoom. Overview mode: 1x -
10x depending on distance of object
Temperature: Storage: -10°C to +40°C. (15°F to 100°F)
Operating: +5°C to +35°C (40°F to 90°F)
As we strive to constantly improve our products, this information is subject to change
without notice.
