– 17 –
Type 2089 (0.05% accuracy), 2086 (0.10% accuracy),
2084 (0.25% accuracy)
Accuracy 0.05%, 0.10%, 0.25% all Full Scale Terminal Point Total
Error Band (TEB) Accuracy Including Hysteresis,
Linearity, Repeatablilty & Temperature (–18/65°C)
(0/150°F)
Dial Size 3"
Case Material
300 Series SS
Case Finish Electropolished
Case Enclosure Rating
Weatherproof, IP65
Socket Material
316 SS
Socket Size
1
⁄
4 NPT Male (others on application)
Connection Location
Lower, 3:00, 9:00
Ranges Vac thru 7000 psi (see engineering units below for other
units of measurement)
Operating Temperature
0/150°F
Storage Temperature
–40/180°F
DISPLAY:
Type LCD
Display Digits 5
Character Height .66˝
Backlit Off By Default
Bar Graph Yes
Battery Life 1000 Hrs.
Agency Approvals
CE, FM, CSA (FM/CSA approval not available on vacuum
range & compound ranges up to 15 psi)
KEYPAD FUNCTIONS:
On/Off Manually Turns Unit On & Off
(auto off options in config menu)
Backlit Manually Turns Backlit On & Off
(auto off options in config menu)
Min/Max Stores Min & Max Values
Zero/Clear Zeros Display or Clears Min/Max Values When Displayed
SPECIFICATIONS
I&M008 10080 Rev. E_layout 10/14/13 9:35 AM Page 17
