-26-
In order to maintain warranty, components must be replaced using original manufacturers parts purchased
through your dealer or directly from the appliance manufacturer. Use of third party components will void
the warranty.
Replacement Parts
Wooden Handle
89520 1
Board, Ceraminc Fiber
892726 2
Secondary Tube
86870 6
Brick Retainer
27879 2
Slide Plate Assembly
610750 1
Right Shoulder
28015 1
Blower Assembly
80594 2
Back Plate Assembly
610751 1
Front Liner
27937 1
Blower Gasket
89319 2
Cover Weldment
610752 1
Transformer, Fan Center
80130 1
Left Shoulder
28016 1
Wire Guide
28746 1
Cable Clamp
83785 1
Filter Box, Side Panel
28706 2
