Ashley APC1406 - Page 27

USSC 27
PARTS LIST - APC1406
1 25523 Cast Leg, Painted 4
2 69622MB Ash Pan Weldment 1
3 25425 Guide Rail, Ash Pan 2
4 891137 Handle, Nickel 1
5 25533 Damper/Cleanout Guide 2
6 25532 Cleanout Guide 2
7 25531 Ash Cleanout (Lower) 2
8 69528 Damper 1
9 891660 Burnpot 1
10 891059 Agitator 1
11 83529 Hair Pin 2
12 25524 Ash Cleanout (Inner) 2
13 69593 Igniter Tube Weldment 1
14 88118 Igniter Flange Gasket 1
15 80543 Igniter Cartridge 1
16 69516 Feed Door Assembly 1
17 891135 Spring Handle (Large) 1
18 25080 Door Latch 1
19 891705 Vermaculite Board (Herringbone) 1
20 891858 Louver Assembly 1
21 88116 Insulation (Kaowool) 1
22 86627 Exhaust Duct 1
23 88114 Exhaust Duct Weldment 1
24 80473 Exhaust Blower 1
25 88100 Exhaust Blower Gasket 1
26 80472 Distribution Blower 1
27 88106 Distribution Blower Gasket 1
28 69598 Hopper Assembly - Complete 1
29 80491 Micro Switch 1
30 891164 Auger Housing Weldment 1
31 891141 Auger 1
32 891132 Bottom Bushing
(
Retaining Ring - Pt #: 83534)
1
33 69514 Top Bushing Plate Assy. 1
34 891248 Bottom Plate Retainer 1
35 891195 Drive Motor Bracket 1
36 891169 Hose (2 per) 0.167 ft
37 891180 Auger Cover
38 88120 Gasket, 0.188 x 1.0 Flat FbrGlss. 0.25 ft
39 80488 Drive Motor (Auger) 1
40 80456 Drive Motor (Agitator) 1
41 891083 Sprocket, Motor 1
42 891057 Sprocket, Shaft 1
43 891058 Chain - 36 Links 1
44 69594 Primary Bushing Assembly 1
45 88111 Agitator Bracket Gasket 1
46 69595 Secondary Bushing Assembly 1
47 891706 Drive Shaft - Agitator 1
48 80549 Pressure Switch 1
49 25648 Pressure Switch Bracket 1
50 891121 Silicone Hose 0.4 ft
51 83564 Hose Clamp 1
52 89586 Auger Nipple 1
53 80381 110°F Snap Disc (Low Limit) 1
54 80390 170°F Snap Disc (High Limit) 1
55 69506 Cabinet Support, Top/Left 1
56 25448 Support Frame, Back/Left 1
57 69505 Cabinet Support, Top/Right 1
58 25447 Support Frame, Back/Right 1
59 25412 Right Cabinet Side 1
60 25411 Left Cabinet Side 1
61 80575 PCB, Circuit Board 1
N/S 80485 Wiring Harness, Main 1
62 25682 Cabinet Back 1
63 80462 Receptacle, 3-Prong 1
64 80461 Power Supply Cord 1
65
891707 Top/Lid Assembly 1
66
67 891148 Plastic Handle 1
N/S = Not Shown
Key Part No. Description Qty.
Key Part No. Description Qty.
Key Part No. Description Qty.
Key Part No. Description Qty.
