APC1406 ASSEMBLY
1
1
2
2
A A
B B
Assembly
1. Unpack unit and make sure all components are included; (4) Legs,
and all hardware for installation.
2. Fold the corner padding from the carton and lay it on the oor behind
the unit. This is used to hold the heater up off the oor to install the
legs. Gently tilt the heater on its back, door opening up.
3. Assemble the legs as shown using the eight(8) 1/4-20 bolts supplied.
4. After all bolts and screws have been tightened properly, carefully
set the heater back up on the legs.
