USER GUIDE XGA LCD PROJECTOR
40
14.2 PROJECTOR UNIT
PROJECTOR DIMENSIONS
(H x W x L)
137 x 249 x 295 (375) mm /
5.4 x 9.8 x 11.6 (14.7) inch
PROJECTOR WEIGHT 5 kg / 11 lbs
PROJECTION LENS Manual zoom and focus lens
1.3 zoom ratio
f 45-59 mm
F 2.5-3.0
IMAGE SIZE 0.76 - 7.6 m / 30 - 300 inches (wide)
0.58 - 5.5 m / 23 - 230 inches (tele)
PROJECTION DISTANCE 1 - 10 m / 3.3 - 33 ft
ANTI-KEYSTONE CORRECTION 12 degrees
PROJECTION LAMP 150 W metal halide
LIGHT OUTPUT 650 ANSI lumen
CELL 1.3” polysilicon TFT LCD
COLOR RESOLUTION 16.7 million
CONTRAST RATIO 300:1
PIXEL RESOLUTION 1024 x 768 x 3
DEFECTIVE PIXELS 10 (max)
VIDEO FREQUENCY 12 - 150 MHz
HORIZONTAL SYNC 15 - 100 kHz
VERTICAL SYNC 43.5 - 130 Hz
COMPUTER INPUT 0 - 1 Vpp
AUDIO INPUT 1V RMS
SPEAKERS 4 x 1 W speakers
APPROVALS
• CE
• UL
• cUL
• FCC Class A, Subpart J, Part 15
14.3 POWER SUPPLY
DUAL VOLTAGE 100 - 120 VAC, 60 Hz, +/- 10 %
220 - 240 VAC, 50 Hz, +/- 10 %
250 W operating, 15 W standby
