15.2 MOUSE
This port is used to relay mouse signals from the projector to the computer.
8 PIN MINIDIN
FEMALE
(FRONT VIEW)
1
2
3
4
5
6
7
8
1
2
3
4
5
PS/2 CLOCK
RS232 TXD
RS232 RTS
RS232 RXD
RS232 CTS
6
7
8
PS/2 DATA
MAC ADB
GND
15.3 LINE OUT
This connector is used for stereo sound output.
3.5 mm
JACK
(FRONT VIEW)
TIP
STEM
COMMON
RIGHT
RING
LEFT
