12
Mounting the extensible cover plate
Run the power supply so that it fits inside the
cover plate.
Adjust the mounting plate by pulling it apart or
pushing it together so that it fits the cover plate.
Then screw the mounting plate to the wall (A).
Screw the cover plate to the mounting plate (B).
If installing as in alternative B (outdoor venting),
you must now fit an approved ventilation tube
that can be purchased from the same store as the
cooker hood. Fit following the instructions includ-
ed with the tube. Connect the ventilation tube to
the connecting flange of the cooker hood (C).
NB:
If the cooker hood is installed as in alternative A
(circulating indoor air), the charcoal filter availa-
ble for purchase from your dealer must be fitted.
INSTALLATION
High ceiling?
If the ceiling is higher than 2.60-2.70 metres, for
certain models you can order a chimney extender
for ceiling heights up to 3.5 metres.
