Specifications are subject to change without notice. See installation instructions for additional details.
11
ASKO DISHWASHER
MODEL D1996SS
The electrical and water supplies should
enter through the area indicated by the
shaded area. Preferably, they should come
through the right side of the machine. The
access hole must be round and smooth
and no bigger than 2" in diameter.
TECHNICAL DATA
Electricity 120V, 60Hz, 15 amp
Water pressure 18-176 psi
Heating element 1400 watt
Max loading 1600 watt
FRONT PANELS
Model D1996SS is not designed to accept
a custom front panel. Even though the
controls are on top of the door, this model
installs like a standard ASKO dishwasher. It
fits in American cabinets (4" toe kick) with
a 24" wide opening.
CUTOUT DIMENSIONS
US Metric
Height 32-1/4"–35-1/2" 819–902 mm
Width 24" 610 mm
Depth* 23-7/16" 596 mm
*This depth allows a 1" (25 mm) space for
the high-loop drain hose.
NOTE: Maintain a 1/8" (3 mm) minimum
clearance between unit and cabinet.
EASYINSTALL SYSTEM
Every ASKO dishwasher comes with the
unique EasyInstall System that speeds the
installation and reduces problems. This
system has these components which are
approved by regulatory authorities (cUL):
• Over 5' of Pex hose that replaces the
water-inlet copper tubing. It has a 3/8"-
compression fitting that mates with the
shut-off valve.
• Over 6' of drainhose with an adaptable
drain connection.The high loop is built
into this hose on the back of the unit. If
this loop is removed to lengthen the
hose, another high-loop must be built
into the installation somewhere along
the line (typically where the hose passes
through the cabinet).
• A 6' long electrical cord with standard,
3-pronged, 110V plug. This eliminates
the need to wire anything under the unit.
