Specifications are subject to change without notice. See installation instructions for additional details.
3
ASKO DISHWASHER
MODEL D1716
The electrical and water supplies should
enter through the area indicated by the
shaded area. Preferably, they should come
through the right side of the machine. The
access hole must be round and smooth
and no bigger than 2" in diameter.
TECHNICAL DATA
Electricity 120V, 60Hz, 15 amp
Water pressure 18-176 psi
Heating element 1400 watt
Max loading 1600 watt
FRONT PANELS
The front panels on Model D1716 (except
the stainless steel model) can be covered
or replaced with wood panels. See page 6
for instructions on how to change the front
panels.
CUTOUT DIMENSIONS
US Metric
Height 32-1/4"–35-1/2" 819–902 mm
Width 24" 610 mm
Depth 23-7/16" 596 mm
*This depth allows a 1" (25 mm) space for
the high-loop drain hose.
NOTE: Maintain a 1/8" (3 mm) minimum
clearance between unit and cabinet.
EASYINSTALL SYSTEM
Every ASKO dishwasher comes with the
unique EasyInstall System that speeds the
installation and reduces problems. This
system has these components which are
approved by regulatory authorities (cUL):
• Over 5' of Pex hose that replaces the
water-inlet copper tubing. It has a 3/8"-
compression fitting that mates with the
shut-off valve.
• Over 6' of drainhose with an adaptable
drain connection.The high loop is built
into this hose on the back of the unit. If
this loop is removed to lengthen the
hose, another high-loop must be built
into the installation somewhere along
the line (typically where the hose passes
through the cabinet).
• A 6' long electrical cord with standard,
3-pronged, 110V plug. This eliminates
the need to wire anything under the unit.
