With fill strips** Without fill strips
H minimum ** H maximum H minimum *** H maximum
With toe kick
(see Steep 7)
34-1/4”, 870 mm 35”, 890 mm 33-3/4”, 860 mm 34-5/8”, 880 mm
Without toe
kick
34-1/4”, 870 mm 36-1/8”, 920 mm 33-3/4”, 860 mm 35-3/4”, 910 mm
* With fill strips and without plastic feet.
**
ASKO XLFI dishwashers can be installed either with or without accessory fill strips depending on the
type of installation. If the dishwasher cutout has been cut to European widths of 23-5/8” (600 mm), the unit
won’t require fill strips. If the dishwasher cutout is a standard 24” wide, we have fill strips that make the unit
24” (610 mm) wide.
*** Without plastic feet.
Make sure the edges of the cable
hole are even to avoid damage to
the drain and supply hoses and
the electric cable.
Cable hole
H - see table below
