Adjust the height and slide the
dishwasher into place
1.
Attach the coasters (if applicable) to the
dishwasher.
2.
Start by measuring the height from the floor to the
bottom edge of the worktop.
3.
Measure the height from the floor to the top edge
of the dishwasher.
4.
Adjust all feet by turning them clockwise to raise
or anticlockwise to lower the dishwasher.
5.
Check that there is an air gap of at least 3 mm
between the underside of the worktop and the top
edge of the dishwasher.
6.
Tighten the lock nuts (lock nut) on the rear feet.
7.
Slide the dishwasher into place.
•
Pull through the drainage and supply hoses
when the machine is slid into place.
•
Check that the hoses have no kinks or sharp
bends, and check that there is nothing that can
damage the hoses.
8.
Make any final adjustments to the front feet (the
dishwasher may lean no more than 5 mm) and
tighten the lock nuts.
If you want to install your dishwasher freestanding,
skip steps 2, 3 and 5 above.
