Screwing the dishwasher into place
(Applicable only to built-in dishwashers.)
After fastening the machine, check that the front feet still touch
the floor.
Adjusting the plinth (only when using
toe kick accessory)
The dishwasher is supplied with one or two toe kicks depending
on the model. The table shows which toe kick you should use
depending on the recess height and plinth depth.
Plinth depth (mm)Recess height (mm)
10090807060504030
LLLN/AN/AN/AN/AN/A820
LLLLN/AN/AN/AN/A830
LLLLLLLL840
HHHN/AN/AN/AN/AN/A850
HHHHN/AN/AN/AN/A860
HHHHHHHH870
Low toe kick (height=90 mm), article number 80 735 66L
High toe kick (height=120 mm), article number 80 735 67H
Not recommended for aesthetic reasons.N/A
Recess height
Plinth depth
22
