Installation instructions
32 3/4 - 34 7/8
22
28 1/8
24*
5 1/8 - 7 3/8
2
4 1/4
47 1/8
28
['']
Nominal dimensions. Actual measurements may vary.
* If European widths of 23 5/8'' (600 mm) is required, remove the trim kit.
Important safety instructions
• Connections to electricity, water, and drainage must be performed
by a qualified professional.
• Always follow applicable regulations for water, drainage, and
electricity.
• Take care during installation! Wear protective gloves! There must
always be two people!
• Place a drip tray on the floor beneath the dishwasher to prevent
damage from any water leaks.
• Before screwing the dishwasher into place, test the dishwasher by
running the Rinse and hold program. Check that the dishwasher
fills with water and drains. Also check that none of the connections
leak.
WARNING!
Turn off the water supply when installing the dishwasher!
The plug must be disconnected or power to the outlet turned off while
installing the dishwasher!
Transport protection for the door
Do not forget to remove the transport protection for the door when
unpacking the dishwasher.
Trim kit
The dishwasher is equipped with a trim kit to fit the 24'' (610 mm) cutout
standard. If a European width of 23 5/8'' (600 mm) is required, remove
the trim kit.
Adjust the trim kit
The trim kit can be adjusted backward to level the dishwasher tub.
2
