Asko DBI663PHS Installation Instructions

Placing the dishwasher
The dishwasher is intended to be built in under a countertop. The
built-in measurements are shown in the illustration. Make sure that the
cord and hose hole's edges are even and will not damage the drain
and inlet hoses or the power cord.
24
5 3/8
2
4
24
32 3/4* - 34 3/4
['']
*32 1/4'':
The electrical and
water supplies should
enter through the area
indicated by the
shading on the
illustration.
Remove the trim kit.
NOTE!
Framed cabinets require additional finished filler material behind the
face frame for a proper installation. A minimum 3½” (89 mm) finished
return is required on all sides of the opening.
3½”
¾”
3½”
Frameless
cabinetry
Filler
Framed
cabinetry
Fit the protective film
Fit the protective film (packed in the document bag) to the underside
of the countertop. The protective film is to protect the countertop from
moisture.
NOTE!
The surface to which the protective film is fitted must be clean and
dry.
3

Asko DBI663PHS Specifications

General

Style	built in
Color	stainless steel
Load Capacity	16 place settings
Number of Cycles	normal wash, eco wash, hygiene wash, time program, plastic wash, rinse and hold, sanitation wash, upper half, lower half, crystal glass, self-cleaning; 11
Drying Type	turbo drying; vented
Noise level	44 dba
Control Type	touchpad
Delay Start	yes
Spray Arms	3
Water Filter	yes
Leak Protection	no
Water Softener	no
Food Disposer	no
Sanitize Settings	no
Half Load	yes
Wi-Fi	no
Smart Home	no
Remote Control	no
Voltage	120 volts
Frequency	60 hz
Current	15 a

Weight and Dimensions

Depth	22 inch
Height	33 3/4 inch
Width	23 7/8 inch
Net Weight	115 lbs.
