26
Technical Information
*) Given values may vary depending on the rotation speed during spin-drying
Air gap left during mounting
Rekommended is a minimum space of 10 mm
above and behind the drying cabinet.
Evacuation/Air intake
When the cabinet is on, 45 m³ of humid air are evacuated per hour.
Technical characteristics
Capacity: approximately 3.5 kg washing (cotton)
Water removal rate : 17.5 grams per minute
Electricity connection: Single phase 220 - 240 V, 50-60 Hz
Motor: 35 W
Heating element power consumption:
1500 W
Protection against overheating: Yes
Timer: Adjustable, up to 4 hours
Hanging length: 16 metres
Dimensions: Height 1730 mm
Adjustable between 1720 mm and 1745 mm.
Width 595 mm.
Depth 610 mm,
Weight: ~60 kg
Colour: White, titanium or grey
Sound level: maximum 58 dB (A)
Energy consumption and drying time
Spun-dried washing *)
Setting Energy consumption Drying time Temperature
Position 2 (Low) 0.6 kWh/kg washing approx. 180 minutes 45 °C
Position 3 (Normal) 0.7 kWh/kg washing approx. 120 minutes 65 °C
Manufacturing standards
See the identification plate
