43
6.3 Fault codes
In the fault codes below, “L ” denotes LED and
“F” denotes fault code on the display.
LED L1/Fault code F1, Temperature stop fault (no
indication in DW20.1)
The temperature rise is less than 5°C in ten
minutes. The programme exits from the heating
stage and continues in the process. Indication
only in the service menu.
Check: Element, thermistor, water level,
circulation pump and control unit, wiring.
LED L2/Fault code F2, Overfilling
Too much water in the machine (pressure sen-
sor) or float activated. If the water has not been
evacuated within 60 seconds, the programme will
be interrupted (drain pump activated).
Check: Drain pump (blockage in hoses), flow
sensor, inlet valve, leakage, wiring.
LED L3/Fault code F3, Thermistor fault (no
indication in DW20.1)
Interruption or >80°C. The programme exits
from the heating stage and continues in the
process. Indication only in the service menu.
Check: Thermistor, control unit.
LED L4/Fault code F4, Water intake fault (no
indication in DW20.1)
< 80 pulses within 60 seconds or correct number
of pulses is not achieved within 255 seconds.
Programme interrupted.
Check: Water supply, flow sensor, inlet valve,
wiring.
LED L11/Fault code F5, Valve leakage (no
indication in DW20.1)
> 80 pulses detected when the inlet valve is
deactivated. Certain models attempt to remedy
the leak first.
Any programme in progress is interrupted (drain
pump activated).
Check: Leakage through inlet valve, flow sensor.
TROUBLESHOOTINGTROUBLESHOOTING
TROUBLESHOOTINGTROUBLESHOOTING
TROUBLESHOOTING
LED L12/Fault code F6, Pressure sensor fault
Output signal > 4.8V. The programme continues.
Indication only in the service menu.
Check: Pressure sensor, control unit and wiring.
LED L1+L2/Fault code F7, Pumping out fault
(machines with pressure sensor)
Water not evacuated after 120 seconds’ pumping
out. Programme interrupted.
Check: Drain pump, hoses, installation of drain
hose, control unit and wiring.
LED L1+L3/Fault code F8, Blocked filter
The pressure sensor senses excessively low
pressure during the final rinse. Indication after
end of programme.
Check: Filter, sump (pressure chamber),
pressure sensor.
LED L1+L4/Fault code F9, Circulation fault
The pressure sensor senses excessively low
pressure (e.g. no water in the machine) or
excessively high pressure (e.g. the circulation
pump is defective). The programme exits from
the heating stage and continues in the process.
Indication only in the service menu.
Check: Circulation pump, filter, water level,
pressure chamber and pressure sensor.
LED L1+L11/Fault code FA, Turbidity sensor fault
Indication only in the service menu. The machine
assumes high turbidity for “choice of route” in
the automatic programme.
Check: Water quality, filter, turbidity sensor,
drain system.
LED L1+L12/Fault code FB, Spray arm divider fault
Position contact is continuously closed or open.
The programme proceeds. Indication only in the
service menu.
Check: Spray arm divider (function of gearbox,
contacts and wiring).
LED L7/Salt indication (DW20.5)
LED L6/Rinse aid indication (DW20.5)
LED L7/Fault code, Door open
LED L7/Fault code, Close door
