2.2 Components and measured values
Indicated resistance values apply at room temperature (ca. 20°C/68°F)
Values within ±10% are regarded as normal
Item No. Component Measured value Position
8073779 Radio interference suppression filter 680 kohm
8073780,81 Radio interference suppression filter 1 Mohm
8073784 Heating element 1800 W 230 V 30 ohm
8073785 Heating element 1200 W 120 V 12 ohm
8073788 Thermistor 25 kohm
8073801,02 Combined dispenser 230 V 1.3 kohm
8073803,04 Combined dispenser 120 V 0.3 kohm
8073811 Circulation pump 200-240 V 50 HZ 90 ohm
8073812 Circulation pump 200-220 V 60 HZ 56 ohm
8073813 Circulation pump 120 V 60 HZ 22 ohm
8073816 Drain pump 200-240 V 50 HZ, 16 l/m 150 ohm
8073817 Drain pump 200-220 V 60 HZ, 16 l/m 85 ohm
8073818 Drain pump 120V 60 HZ, 16 l/m 25 ohm
8073821 Spray arm divider 200-240 V 50/60 HZ 8,5 kohm 2-3
8073822 Spray arm divider 120 V 60 HZ 2.6 kohm 2-3
8073824 Inlet valve single incl. flow sensor 200-240 V, 4 l/m 3.8 kohm coil
8073825 Inlet valve single incl. flow sensor 120 V, 4 l/m 0.95 kohm ”
8073826 Inlet valve safety incl. flow sensor 200-240 V, 4 l/m 2 kohm ”
8073827 Inlet valve safety incl. flow sensor 120 V, 4 l/m 0.5 kohm ”
8074337 Inlet valve water soft incl. flow sensor 200-240 V, 4 l/m 3.8 kohm ”
8074338 Inlet valve water softener incl. flow sensor 120 V, 4 l/m 0.95 kohm ”
8073830 Halogen lamp 5 W/12 V <10 kohm
8052778 Wax motor 1.1 kohm
8073847 Fan motor 230 V 0.75 kohm
8073848 Fan motor 120 V 0.18 kohm
8081321 Heavy soil sensor
