DW 950 / 951 / 952 / 95C
ELECTRICAL SUPPLY
As delivered , the machines are wired for connection to a single-phase, 230 V,
10 A supply, with a heater MAIN SWITCH
The main switch is a 2-pole switch, interrupting both the phase and neutral
supplies. power of 1800 W, giving a total power requirement of 2000 W.
Alternative:single-phase, 230 V, 16 A, heater power 3000 W total power
requirement 3200 W . Altemative: 2-phase, 400 V, 10 A, heater power 3000
W total power requirement 3200 W.
SOFTNER
On certain models sensor for rinse aid level is mounted on the softner. This
indicates by lack of salt.
FAN
Evacuates the moist air from the machine during the drying phase of the pro-
gram.
The fan system consists of a fan motor which runs a two part impeller. Dry air
is sucked in from the door into one of the impeller halves. A vax motor opens a
valve, and the moist air streams into the other part of the impeller. Dry and moist
air are mixed and led into a channel to the lower part of the door, where it is let
out.
