EN 43
Replacing the oven light bulb
The light bulbs (2x) (halogen G9, 230 V, 25 W) are a consumer items
and therefore not covered by warranty. To replace it, first remove the
baking tray, oven rack and guide rails.
Disconnect the appliance from the power supply by removing the plug
from the socket or by switching off the circuit breaker in the fuse box.
Please note: the light bulb can be very hot! Use protection to remove
the bulb.
1. Unscrew the cover panel’s four screws. Remove the cover panel
and glass.
2. Remove the faulty halogen lamp and replace it with a new one.
To prevent burns, use protection to remove the lamp.
3. Do not remove the seal from the cover panel.
The seal should not become lose from the cover panel. The seal
needs to fit perfectly in the oven wall recess.
CLEANING
