309421 15
Tip Selection
Understanding the Tip Number
The last three digits of the tip number (example:
59–413) contain information about the hole size and
about the fan width on the surface when the gun is
held 12 in. (30.5 cm) from the surface being sprayed.
First digit when doubled
= approximate
fan width.
Last two digits = tip hole size
in thousands of an inch.
413 tip has a
0.013 in. hole size
413 tip has 8 to 10 in.
fan width
