309421 7
Component Identification and Function
A Electric motor (inside of enclosures) Provides mechanical power to pump
B Power switch For manually turning on/off electrical power to motor (“I” is ON / “0” is OFF)
C Pressure Control knob For manually increasing (turn clockwise) and decreasing (turn
counter-clockwise) fluid pressure in pump, hose, and spray gun
D Pump fluid outlet fitting Threaded connection for paint hose
E Fluid filter D Filters fluid coming out of pump to reduce tip plugging and improve finish
D Self cleans during pressure relief
F Piston pump (behind black cap) Pumps and pressurizes fluid and delivers it to paint hose if necessary. Black
cap permits quick removal of outlet valve.
G Suction tube Draws fluid from paint pail into pump
H Prime tube (with diffuser) Drains fluid in system during priming and pressure relief
J Spray/Prime/Drain valve control D Directs pressurized fluid to paint hose in SPRAY position (pointing forward)
D Directs fluid to drain tube in PRIME/DRAIN position (pointing down)
D Automatically relieves system pressure in overpressure situations
K Fluid inlet connection and inlet valve Where suction tube connects to pump and inlet valve
L Inlet screen Prevents debris from entering pump
M Paint hose Transports high-pressure fluid from pump to spray gun
P Airless spray gun Manually-controlled, hand-held on/off device for fluid being sprayed
Q Tip base Reduces risk of fluid injection injury
R Super Zip spray tip D Atomizes fluid being sprayed, forms spray pattern, and controls fluid flow
according to hole size
D Reverses for unplugging without disassembly
S Trigger safety lever Prevents accidental triggering of spray gun
T Gun fluid inlet fitting Threaded connection for paint hose
U Swivel Allows spray gun to swivel without twisting paint hose
V Gun fluid filter (in handle) Filters fluid entering spray gun to reduce tip plugging and improve finish
W Hose/Cord wrap bracket Stows paint hose and electrical cord
X Pail hanger For transporting pail by its handle
