2.4 Expansion Slots (PCI Express Slots)

ere are 4 PCI Express slots on the motherboard.

PCIe slots:

PCIE1 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.

PCIE2 (PCIe 3.0 x1 slot) is used for PCI Express x1 lane width cards.

PCIE3 (PCIe 3.0 x1 slot) is used for PCI Express x1 lane width cards.

PCIE4 (PCIe 3.0 x16 slot) is used for PCI Express x4 lane width graphics cards.

* If PCIE2 is occupied, PCIE4 will downgrade to x2 mode.

PCIe Slot Congurations

For a better thermal environment, please connect a chassis fan to the motherboard’s

chassis fan connector (CHA_FAN1 or CHA_FAN2) when using multiple graphics

cards.

Before installing an expansion card, please make sure that the power supply is

switched o or the power cord is unplugged. Please read the documentation of the

expansion card and make necessary hardware settings for the card before you start

the installation.

PCIE1 PCIE4

Single Graphics Card x16 N/A

Two Graphics Cards in

CrossFireX

Mode

x16 x4
