ASROCK Fatal1ty H87 Performance Series User Manual

2
English
1.2 Specications
Platform
•
ATX Form Factor
•
ASRock DuraCap (2.5 x longer life time) (100% Japan-made
high-quality Conductive Polymer Capacitors)
A-Style
•
Home Cloud
•
Purity Sound
TM
•
HDMI-In
Gaming
Armor
CPU Power
•
Hi-Density Power Connector
VGA Card
•
15μGold Finger in VGA PCIe Slot (PCIE2)
Internet
•
Intel® LAN
CPU
•
Supports 4
th
Generation Intel® Core
TM
i7 / i5 / i3 / Xeon® /
Pentium® / Celeron® in LGA1150 Package
•
Digi Power Design
•
8 Power Phase Design
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® H87
•
Supports Intel® Small Business Advantage 2.0
Memory
•
Dual Channel DDR3 Memory Technology
•
4 x DDR3 DIMM slots
•
Supports DDR3 1600/1333/1066 non-ECC, un-buered
memory
•
Max. capacity of system memory: 32GB
(see CAUTION)
•
Supports Intel® Extreme Memory Prole (XMP)1.3/1.2
•
Distortion-Free Slot
Expansion
Slot
•
1 x PCI Express 3.0 x16 slot (PCIE2: x16 mode)
•
1 x PCI Express 2.0 x16 slot (PCIE4: x4 mode)
•
If PCIE1 or PCIE3 slot is occupied, PCIE4 slot will run at x2
mode.

ASROCK Fatal1ty H87 Performance Series Specifications

General

Chipset	Intel H87
CPU Socket	LGA 1150
Form Factor	ATX
Max Memory	32GB
Memory Standard	DDR3 1600/1333/1066
PCI Express 3.0 x16	1
PCI Express 2.0 x16	1
PCI Express x1	2
PCI Slots	2
SATA 6Gb/s	6
Audio Chipset	Realtek ALC1150
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4
USB 2.0 Ports	6
LAN	Gigabit LAN
Audio	7.1 Channel HD Audio
