ASROCK Fatal1ty X99 Professional Series User Manual

English
8
9
Fatal1ty X99 Professional Series
No. Description
1 2 x 284-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
2 2 x 284-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
3 8 pin ATX 12V Power Connector (ATX12V1)
4 4 pin ATX 12V Power Connector (ATX12V2)
5 CPU Fan Connector (CPU_FAN1)
6 2 x 284-pin DDR4 DIMM Slots (DDR4_D2, DDR4_C2)
7 2 x 284-pin DDR4 DIMM Slots (DDR4_D1, DDR4_C1)
8 CPU Fan Connector (CPU_FAN2)
9 Rapid OC Button (+) (PLUS)
10 Rapid OC Button (–) (MINUS)
11 Menu Button (MENU)
12 PCIe ON/OFF Switch (SWITCH1)
13 LN2 Mode Switch (LN2MODE)
14 Slow Mode Switch (SLOWMODE)
15 V-Probe
TM
(VOL _CON1)
16 Post Status Checker (PSC)
17 ATX Power Connector (ATXPWR1)
18 USB 3.0 Header (USB3_7_8)
19 Vertical Type A USB 3.0 (USB3_8)
20 Chassis Fan Connector (CHA_FAN3)
21 USB 3.0 Header (USB3_9_10)
22 SATA3 Connectors (S_SATA3_0_1)
23 SATA3 Connectors (S_SATA3_2_3)
24 SATA3 Connectors (SATA3_0_1)
25 SATA3 Connectors (SATA3_2_3)
26 SATA3 Connectors (SATA3_4_5)
27 HDD Saver Connector (SATA_PWR_1)
28 BIOS Selection Switch (BIOS_SEL1)
29 Power LED Header (PLED1)
30 Direct Key Button (DIRKEY1)
31 Chassis Speaker Header (SPEAKER1)
32 System Panel Header (PANEL1)
33 Power Switch (PWR)

ASROCK Fatal1ty X99 Professional Series Specifications

General

Chipset	Intel X99
CPU Socket	LGA 2011-v3
Memory Slots	8 x DIMM
Maximum Memory	128GB
Memory Type	DDR4
SATA 6Gb/s Ports	10
M.2 Slots	1
Form Factor	ATX
RAID Support	RAID 0, 1, 5, 10
PCI Express x1 Slots	1 x PCIe 2.0 x1
Storage Interface	SATA 6Gb/s
LAN	Dual Gigabit LAN
Audio	Realtek ALC1150
Multi-GPU Support	AMD 3-Way CrossFireX
USB Ports	10 (6 rear, 4 via headers)
Ethernet	Dual Gigabit LAN
