ASROCK Fatal1ty X99M Killer Series User Manual

Fatal1ty X99M Killer Series
15
English
2.3 Installation of Memory Modules (DIMM)
is motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots, and
supports Quad Channel Memory Technology.
Quad Channel Memory Conguration
DDR4_A1
Populated
DDR4_B1
Populated
DDR4_C1
Populated
DDR4_D1
Populated
•
If only two memory modules are installed in the DDR4 DIMM slots, then Dual
Channel Memory Technology is activated. If three memory modules are installed, then
Triple Channel Memory Technology is activated. If four memory modules are installed
in the DDR4 DIMM slots, then Quad Channel Memory Technology is activated.
1. For quad channel conguration, you always need to install identical (the same
brand, speed, size and chip-type) DDR4 DIMM pairs.
2. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4
slot; otherwise, this motherboard and DIMM may be damaged.
3. e DIMM only ts in one correct orientation. It will cause permanent damage to
the motherboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.

ASROCK Fatal1ty X99M Killer Series Specifications

General

Chipset	Intel X99
Form Factor	Micro ATX
CPU Socket	LGA 2011-3
Memory Slots	4 x DIMM
Maximum Memory	64GB
Memory Type	DDR4
PCI Express x1 Slots	1
Audio Chipset	Realtek ALC1150
RAID Support	RAID 0, 1, 5, 10
Memory Support	DDR4 3000+(OC)/2800(OC)/2400(OC)/2133
SATA Ports	10 x SATA3 6.0 Gb/s
SATA Express	1 x SATA Express
M.2 Slots	1 x M.2
USB 2.0 Ports	6
Audio	7.1 CH HD Audio
LAN	Intel I218V
Multi-GPU Support	NVIDIA Quad SLI, AMD 3-Way CrossFireX
USB 3.0 Ports	6 (4 Rear, 2 Front)
