2.4 Expansion Slots (PCI Express Slots)
ere are 3 PCI Express slots on the motherboard.
PCIe slots:
PCIE1 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIE2 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width graphics cards.
PCIE3 (PCIe 2.0 x16 slot) is used for PCI Express x4 lane width cards.
PCIe Slot Congurations (For CPU with 40 PCIe lanes)
PCIE1 PCIE2 PCIE3
Single Graphics Card x16 N/A N/A
Two Graphics Cards in
CrossFireX
TM
or SLI
TM
Mode
x16 x16 N/A
Before installing an expansion card, please make sure that the power supply is
switched o or the power cord is unplugged. Please read the documentation of the
expansion card and make necessary hardware settings for the card before you start
the installation.
PCIe Slot Congurations (For CPU with 28 PCIe lanes)
PCIE1 PCIE2 PCIE3
Single Graphics Card x16 N/A N/A
Two Graphics Cards in
CrossFireX
TM
or SLI
TM
Mode
x16 x8 N/A
For a better thermal environment, please connect a chassis fan to the motherboard’s
chassis fan connector (CHA_FAN1 or CHA_FAN2) when using multiple graphics
cards.

ASROCK Fatal1ty X99M Killer Series Specifications

General

Chipset	Intel X99
Form Factor	Micro ATX
CPU Socket	LGA 2011-3
Memory Slots	4 x DIMM
Maximum Memory	64GB
Memory Type	DDR4
PCI Express x1 Slots	1
Audio Chipset	Realtek ALC1150
RAID Support	RAID 0, 1, 5, 10
Memory Support	DDR4 3000+(OC)/2800(OC)/2400(OC)/2133
SATA Ports	10 x SATA3 6.0 Gb/s
SATA Express	1 x SATA Express
M.2 Slots	1 x M.2
USB 2.0 Ports	6
Audio	7.1 CH HD Audio
LAN	Intel I218V
Multi-GPU Support	NVIDIA Quad SLI, AMD 3-Way CrossFireX
USB 3.0 Ports	6 (4 Rear, 2 Front)
