ASROCK Fatal1ty X99M Killer Series User Manual

68
English
tRWDR
Congure Read to Write dierent rank dead cycle Back to back READ to WRITE
from dierent rank separation parameter.
tWRDD
Congure Write to Read dierent DIMM dead cycle Back to back READ to WRITE
from dierent DIMM separation parameter.
tWRDR
Congure Write to Read dierent rank dead cycle Back to back READ to WRITE
from dierent rank separation parameter.
tWWDD
Congure Write to Write dierent DIMM dead cycle Back to back READ to
WRITE from dierent DIMM separation parameter.
tWWDR
Congure Write to Write dierent rank dead cycle Back to back READ to WRITE
from dierent rank separation parameter.
tRRDD
Congure Read to Read dierent DIMM dead cycle Back to back READ to WRITE
from dierent DIMM separation parameter.
tRRDR
Congure Read to Read dierent rank dead cycle Back to back READ to WRITE
from dierent DIMM separation parameter.
ODT WR (CH A)
Congure the memory on die termination resistors' WR for channel A.
ODT PARK (CH A)
Congure the memory on die termination resistors' PARK for channel A.
ODT NOM (CH A)
Use this to change ODT (CH A) Auto/Manual settings. e default is [Auto].
ODT WR (CH B)
Congure the memory on die termination resistors' WR for channel B.

ASROCK Fatal1ty X99M Killer Series Specifications

General

Chipset	Intel X99
Form Factor	Micro ATX
CPU Socket	LGA 2011-3
Memory Slots	4 x DIMM
Maximum Memory	64GB
Memory Type	DDR4
PCI Express x1 Slots	1
Audio Chipset	Realtek ALC1150
RAID Support	RAID 0, 1, 5, 10
Memory Support	DDR4 3000+(OC)/2800(OC)/2400(OC)/2133
SATA Ports	10 x SATA3 6.0 Gb/s
SATA Express	1 x SATA Express
M.2 Slots	1 x M.2
USB 2.0 Ports	6
Audio	7.1 CH HD Audio
LAN	Intel I218V
Multi-GPU Support	NVIDIA Quad SLI, AMD 3-Way CrossFireX
USB 3.0 Ports	6 (4 Rear, 2 Front)
