Page #13 background imageLoading...
Page #13 background image
5
English
Fatal1ty Z270 Gaming-ITX/ac Series
Storage
•
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology
15 and Intel Smart Response Technology), NCQ, AHCI and
Hot Plug*
* If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will
be disabled.
•
1 x SATA Express 10 Gb/s Connector**
** Support to be announced
•
1 x Ultra M.2 Socket, supports type 2260/2280 M.2 SATA3
6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4
(32 Gb/s)***
*** Supports Intel® Optane
TM
Technology
*** Supports NVMe SSD as boot disks
Connector
•
1 x Chassis Intrusion Header
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x CPU Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* e CPU Optional/Water Pump Fan supports the water cooler
fan of maximum 1.5A (18W) fan power.
* CPU_OPT/W_PUMP can auto detect if 3-pin or 4-pin fan is
in use.
•
1 x Chassis Fan Connector (4-pin)
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
•
1 x Front Panel Audio Connector (15μ Gold Audio Connec-
tor)
•
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
•
1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
BIOS
Feature
•
AMI UEFI Legal BIOS with multilingual GUI support
•
ACPI 6.0 Compliant wake up events
•
SMBIOS 2.7 Support
•
CPU, DRAM, PCH 1.0V, VCCIO, VCCST, VCCSA, VCCPLL
Voltage Multi-adjustment

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK Fatal1ty Z270 Gaming-ITX/ac and is the answer not in the manual?

ASROCK Fatal1ty Z270 Gaming-ITX/ac Specifications

General IconGeneral
ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory32 GB
Supported memory clock speeds2133, 2800, 2933, 3200, 3600, 3866, 4000 MHz
Processor socketLGA 1151 (Socket H4)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 seriesi3-6xxx, i3-7xxx, i5-6xxx, i5-7xxx, i7-6xxx, i7-7xxx
USB 2.0 connectors1
Number of SATA III connectors6
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
DisplayPort version1.2
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity5
LAN controllerIntel® I219-V
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Ethernet interface typeGigabit Ethernet
Audio chipRealtek ALC1220
CertificationFCC, CE, WHQL, ErP/EuP ready
Component for-
Power source typeATX
Motherboard chipsetIntel® Z270
Audio output channels7.1 channels
Motherboard form factormini ITX
RAID levels0, 1, 5, 10
DirectX version12.0
Maximum graphics card memory1024 MB
BIOS typeUEFI AMI
ACPI version6.0
Cables includedSATA
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Width170 mm
