1.4 I/O Panel
No. Description No. Description
1 Antenna Ports 10 Central / Bass (Orange)
2 PS/2 Mouse/Keyboard Port 11 USB 3.0 Ports (USB3_78)
3 Optical SPDIF Out Port 12 Intel® underbolt
TM
3 (TB_1)
4 LAN RJ-45 Port* 13 USB 3.0 Ports (USB3_3_4)
5 Side Speaker (Gray) 14 HDMI Port
6 Rear Speaker (Black) 15 DisplayPort 1.2
7 Line In (Light Blue) 16 Fatal1ty Mouse Port (USB3_1)
8 Front Speaker (Lime)** 17 USB 3.0 Port (USB3_2)
9 Microphone (Pink) 18 Clear CMOS Switch
1118 1416
1 2 3
4
15
13
910
6
5
8
7
12
17
