ASROCK G41C-GS User Manual

33
33
3
ContentsContents
ContentsContents
Contents
1 Introduction1 Introduction
1 Introduction1 Introduction
1 Introduction
......................................................................................................
......................................................................................................
...................................................
5 5
5 5
5
1.1 Package Contents.......................................................... 5
1.2 Specifications ................................................................ 6
1.3 Motherboard Layout (G41C-GS / G41C-S) ................... 11
1.4 I/O Panel (G41C-GS) ..................................................... 12
1.5 I/O Panel (G41C-S) ........................................................ 13
2 Installation2 Installation
2 Installation2 Installation
2 Installation
............................................................................................................
............................................................................................................
......................................................
14 14
14 14
14
2.1 Screw Holes ................................................................. 14
2.2 Pre-installation Precautions ........................................... 14
2.3 CPU Installation .............................................................. 15
2.4 Installation of Heatsink and CPU fan ............................. 17
2.5 Installation of Memory Modules (DIMM)......................... 18
2.6 Expansion Slots (PCI and PCI Express Slots) ..................... 20
2.7 Jumpers Setup .............................................................. 21
2.8 Onboard Headers and Connectors .............................. 22
2.9 SATAII Hard Disk Setup Guide ....................................... 25
2.10 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks
Installation ...................................................................... 26
2.11 Driver Installation Guide ............................................... 26
2.12 Untied Overclocking Technology .................................. 26
3 BIOS S3 BIOS S
3 BIOS S3 BIOS S
3 BIOS S
ETUP UTILITYETUP UTILITY
ETUP UTILITYETUP UTILITY
ETUP UTILITY
......................................................................................
......................................................................................
...........................................
27 27
27 27
27
3.1 Introduction .................................................................... 27
3.1.1 BIOS Menu Bar .................................................... 27
3.1.2 Navigation Keys ................................................... 28
3.2 Main Screen................................................................... 28
3.3 OC Tweaker Screen...................................................... 30
3.4 Advanced Screen ......................................................... 34
3.4.1 CPU Configuration................................................ 35
3.4.2 Chipset Configuration .......................................... 37
3.4.3 ACPI Configuration ............................................... 42
3.4.4 Storage Configuration ......................................... 43
3.4.5 PCIPnP Configuration ........................................... 45
3.4.6 Floppy Configuration ........................................... 46
3.4.7 Super IO Configuration ........................................ 47
3.4.8 USB Configuration ............................................... 48
3.5 Hardware Health Event Monitoring Screen .................. 49
3.6 Boot Screen................................................................... 50
3.6.1 Boot Settings Configuration.................................. 50

ASROCK G41C-GS Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR2-SDRAM, DDR3-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	533, 667, 800, 1066, 1333 MHz
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Celeron Dual-Core, Intel Pentium Dual-Core
Processor system buses supported	533, 800, 1066, 1333 MHz
USB 2.0 connectors	2
Number of Parallel ATA connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Cooling type	Passive
Certification	FCC, CE, EuP
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® G41
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	Intel ICH7
Compatible operating systems	Windows 7\\r Windows Vista\\r Windows XP
Supported storage drive interfaces	Parallel ATA, SATA II
Graphics card	GMA X4500
DirectX version	10
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1759 MB
Parallel processing technology support	Not supported
Cables included	SATA
LAN controller	Realtek RTL8111DL
Networking features	Gigabit Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	8 Mbit
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	198 mm
Width	244 mm
